304 Stainless Steel, Pull-Wire Assembly, 1 Wire, 0.005 x 0.018 Wire Size, 11 Fr, 73" Length
$250.00
3/bag
In-Stock: 100
Ships in 1-2 business days
Product Details
| Pull Ring Material | 304 SS |
|---|---|
| Pull Ring OD (in) | 0.148 |
| French Size | 11 |
| Pull Ring ID (in) | 0.138 |
| Wall Thickness (in) | 0.005 |
| Pull Ring Length (in) | 0.1 |
| # Pull Wires | 1 |
| Pull Wire Size (in) | 0.005 x 0.018 |
| Pull Wire Length (in) | 73 |
| Min Pull Force (LBF) | 29.4 |
| Packaging | 3/bag |
| Shipping Dimensions | 15 × 15 × 4 in |
| Shipping Weight | 2 lbs |
Product Description
This 304 stainless steel single wire pull ring assembly features a 0.005 x 0.018 inch wire diameter with a 73-inch length, ideal for steerable catheter prototype development and medical device assembly. The single wire construction provides precise movement control and excellent flexibility for complex medical instrument applications. Each assembly includes a laser-formed ring termination for secure attachment in surgical and laboratory R&D environments. Packaged in convenient 3-unit bags, this pull wire assembly offers immediate value for bench-top builds and engineering quality assurance testing. The cleaned finish ensures reliable performance in rapid prototyping cycles and device movement systems.
