304 Stainless Steel, Pull-Wire Assembly, 1 Wire, 0.008" OD, 55" Length, Gold Plated
$250.00
1/bag
In-Stock: 1
Ships in 1-2 business days
Product Details
| Pull Ring Material | Gold (Au) Plated 304 SST |
|---|---|
| Pull Ring OD (in) | 0.1017 |
| Pull Ring ID (in) | 0.0803 |
| Pull Ring Length (in) | 0.2 |
| # Pull Wires | 1 |
| Pull Wire OD (in) | 0.008 |
| Pull Wire Length (in) | 55 |
| Min Pull Force (lbs) | 8 |
| Packaging | 1/bag |
| Shipping Dimensions | 60 × 2 × 2 in |
| Shipping Weight | 2 lbs |
Product Description
This 304 stainless steel single wire pull ring assembly features a gold-plated finish for enhanced conductivity and corrosion resistance in demanding medical applications. With a 0.1017″ ring outer diameter and 55-inch length, this single-wire configuration provides precise movement control for steerable catheter prototypes and guidewire development. The gold plating ensures excellent electrical performance while maintaining the mechanical strength needed for repeated deflection cycles in laboratory R&D settings. Each assembly is individually bagged for convenient handling and immediate integration into your medical device builds. This pull wire assembly delivers reliable instrument movement and bench-top prototype development. Ideal for rapid iteration in steerable device research and development projects requiring consistent performance.
