Braided Deflectable Catheter Shaft, Baby Blue, PTFE Lined, 65 PPI Distal Deflectable, 50PPI Transition, 40PPI Proximal, 10.36 F, 0.136" ID, 0.168" OD, 43.7" Length
$825.00
1/bag
In-Stock: 11
Ships in 1-2 business days
Product Details
| ID (in) | 0.136 |
|---|---|
| ID Tolerance (in) | 0.004 |
| OD (in) | 0.168 |
| Wall Thickness (in) | 0.016 |
| PPI | 40 Proximal, 50 Transition, 65 Distal |
| Material | Pebax |
| Length (in) | 43.7 |
| Inner Liner Material | PTFE Liner |
| Distal Tip | Pebax 55D Tip 0.197? length |
| Flex Zone | 35D Flex 2.757? length, 45D, 55D |
| Proximal Section | Vestamid ML21 |
| Color | Baby Blue |
| Wire Size | 0.001" x 0.003" flat wire |
| Wire Material | 304 SS |
| French Size | 10.36 |
| Tubing Type | Deflectable Shaft |
| Catheter Type | Deflectable Braided Catheter Shaft |
| Packaging | 1/bag |
| Shipping Dimensions | 73 × 4 × 4 in |
| Shipping Weight | 1 lbs |
Product Description
This deflectable braided catheter shaft features a PTFE liner for low friction and a baby blue Pebax construction with variable PPI braiding (40 proximal, 50 transition, 65 distal) for controlled flexibility and torque response. The medical grade polymer tubing includes a 304 stainless steel flat wire braid for kink resistance and precise deflection in R&D applications. With a 10.36 French size and multi-durometer distal tip design, it supports prototyping of steerable catheter systems. The PTFE inner surface ensures smooth guidewire movement and fluid transfer, while the material selection offers chemical inertness and sterilization compatibility for OEM assembly testing.
