Braided Deflectable Catheter Shaft, Baby Blue, PTFE Lined, 65 PPI Distal Deflectable, 50PPI Transition, 40PPI Proximal, 7.25 F, 0.095" ID, 0.122" OD, 43.7" Length
$825.00
1/bag
In-Stock: 10
Ships in 1-2 business days
Product Details
| ID (in) | 0.095 |
|---|---|
| ID Tolerance (in) | 0.004 |
| OD (in) | 0.122 |
| Wall Thickness (in) | 0.0135 |
| PPI | 40 Proximal, 50 Transition, 65 Distal |
| Material | Pebax |
| Length (in) | 43.7 |
| Inner Liner Material | PTFE Liner |
| Distal Tip | Pebax 55D Tip 0.197? length |
| Flex Zone | 35D Flex 2.757? length, 45D, 55D |
| Proximal Section | Vestamid ML21 |
| Color | Baby Blue |
| Wire Size | 0.001" x 0.003" flat wire |
| Wire Material | 304 SS |
| French Size | 7.25 |
| Tubing Type | Deflectable Shaft |
| Catheter Type | Deflectable Braided Catheter Shaft |
| Packaging | 1/bag |
| Shipping Dimensions | 73 × 4 × 4 in |
| Shipping Weight | 1 lbs |
Product Description
This medical grade polymer tubing features a braided deflectable catheter shaft with variable PPI zones (65 distal, 50 transition, 40 proximal) for controlled flexibility during navigation. The PTFE inner liner ensures smooth fluid transfer while the 304 stainless steel flat wire braiding provides excellent torque response and kink resistance. Constructed from Pebax and Vestamid ML21 medical polymer materials, the baby blue shaft offers visual differentiation and consistent performance. The graduated flex zones with Pebax 55D tip allow precise deflection control ideal for prototyping and OEM catheter assemblies. This medical polymer tube ships individually packaged for immediate R&D use.
