Braided Deflectable Catheter Shaft, Baby Blue, PTFE Lined, 65 PPI Distal Deflectable, 50PPI Transition, 40PPI Proximal, 9.5 F, 0.125" ID, 0.157" OD, 43.7" Length
$825.00
1/bag
In-Stock: 15
Ships in 1-2 business days
Product Details
| ID (in) | 0.125 |
|---|---|
| ID Tolerance (in) | 0.004 |
| OD (in) | 0.157 |
| Wall Thickness (in) | 0.016 |
| PPI | 40 Proximal, 50 Transition, 65 Distal |
| Material | Pebax |
| Length (in) | 43.7 |
| Inner Liner Material | PTFE Liner |
| Distal Tip | Pebax 55D Tip 0.197? length |
| Flex Zone | 35D Flex 2.757? length, 45D, 55D |
| Proximal Section | Vestamid ML21 |
| Color | Baby Blue |
| Wire Size | 0.001" x 0.003" flat wire |
| Wire Material | 304 SS |
| French Size | 9.5 |
| Tubing Type | Deflectable Shaft |
| Catheter Type | Deflectable Braided Catheter Shaft |
| Packaging | 1/bag |
| Shipping Dimensions | 73 × 4 × 4 in |
| Shipping Weight | 1 lbs |
Product Description
This deflectable braided catheter shaft features a medical grade polymer construction with a PTFE liner for low friction and chemical inertness. The variable braid density (40 PPI proximal, 50 transition, 65 distal) provides progressive flexibility and precise control during navigation. Made from Pebax and Vestamid ML21 materials, it offers excellent kink resistance and torque response for complex medical device applications. The baby blue color aids in visual identification during prototyping and assembly processes. Stainless steel braiding enhances durability while maintaining the deflectable performance required for advanced catheter designs.
