Nitinol Twisted Strand, 3 - AWG (0.0201" OD, 0.51 mm OD), 3.280833333 ft Length
$85.00
1/bag
In-Stock: Out of stock
Ships in 1-2 business days
Want to be notified when this product is back in stock?
Request custom quote
Don't want to wait, submit an RFQ and get your ordered started today.
Product Details
| OD (in) | 0.0201 |
|---|---|
| OD Tolerance (in) | 0.0004 |
| Length (in) | 39.37 |
| Length (ft) | 3.280833333 |
| Surface Finish | Blue Oxide |
| Material | Nitinol |
| Material Detail | Nitinol Superelastic Blue Oxide |
| Wire Type | Twisted Strand |
| Construction | 3 Round Wires |
| Packaging | 1/bag |
| Note | Not For Human Use |
| Company Note | Alleima acquired Endosmart in 2022 |
| Shipping Dimensions | 10.2 × 8.6 × 6.7 in |
| Shipping Weight | 1 lbs |
Product Description
Nitinol twisted strand wire is designed for medical device applications requiring superelastic performance. This wire features a 3-strand twisted construction with a 0.51 mm outer diameter and maintains tight dimensional tolerances of 0.0004 inches. The blue oxide surface finish provides consistent friction characteristics and visual identification. Each wire measures 39.37 inches in length and is packaged individually in protective bags. This product is intended for research and development purposes only and is not for human use. The wire construction combines three round nitinol wires in a twisted configuration for enhanced flexibility and torque response.
